Mono inputs 1-12

Microphone input

Type
electronically balanced, discrete input stage

Connector
XLR

Gain
+10 to +60 dB (PAD = -20 dB)

Input impedance
approx. 1,5k O @ 1 kHz

THD + Noise
0.05 %, 20 Hz to 20 kHz, +60 dB gain, -42 dBu at input

Max. input level
+1 dBu (minimum gain)

S/N ratio
95 dB, 20 Hz to 20 kHz, gain 1, 0 dBu at input

Equivalent noise
-90 dB, 20 Hz to 20 kHz, input termination: 150 O

Crosstalk
< -85 dB (channel 1 against channel 2), +60 dB gain, -42 dBu at input

Line input

Type
electronically balanced

Connector
1/4″ TRS connector

Gain
-10 to +40 dB (PAD = -20 dB)

Input impedance
approx. 16k O @ 1 kHz

THD + Noise
0.02 %, 20 Hz to 20 kHz, +20 dB gain, -20 dBu at input

Max. input level
+24 dBu (minimum gain)

S/N ratio
92 dB, 20 Hz to 20 kHz, gain 1, 0 dBu at input

Equivalent noise
-88 dB, 20 Hz to 20 kHz, input termination: 150 O

Crosstalk
< -90 dB (channel 1 against channel 2), gain 1, 0 dBu at input

System specifications

Sampling rate
44.1 and 48 kHz (internal and external)

Signal delay

Frequency response
20 Hz to 20 kHz, +/- 0.1 dB

Faders

Type
100-mm ALPS motorized faders

Resolution
+12 from 0 to -oo dB (256 increments)
A/D converters

Resolution
24-bit delta-sigma AKM

Oversampling
128 times

Dynamic range
116 dB typ.

D/A converters

Resolution
24-bit delta-sigma CRYSTAL

Oversampling
128 times

Dynamic range
106 dB t
Physical

Dimensions
(H * W * D) approx. 6 1/2″ x 171/4″ x 22 1/2″
(163 mm x 438 mm x 572 mm)

Weight (net)
approx. 29 3/4 lbs (13.5 kg)
